RES 5E

Funktion-One

Narrow dispersion Horn-Loaded Loudspeaker

Res 5E is a high intensity, three-way, mid-high loudspeaker with a unique and patented midrange Axhead loading device.

It not only gives incredible efficiency and dispersion control, but also increases high frequency output from the 8" cone driver. This means that the crossover point to the compression driver can be raised to around 6kHz for dramatically reduced distortion compared to conventional compression driver midrange. The Resolution 5E's highly controlled and focused dispersion enables precise tailoring of overall system coverage, simply through the geometry of the array. Unwanted room reflections are thereby substantially reduced, maintaining the enclosure's high intelligibility.

Note: EP6 connector and Neodymium driver options are no longer available. Now fitted with Neutrik NL8 connectors.

Key Features

  • Fully horn-loaded for high efficiency
  • Dedicated installation flying hardware
  • Ground stack securing system available
  • Optional wheelboard and scrim

Technical Specification

Usable Bandwidth (-3DB)
90Hz - 18kHz
Weight
60kg (132lbs)
Nominal Dispersion
25° Horizontal x 20° Vertical
Connectors
2 x Neutrik NL8
Drivers
Driver Operating Band Sensitivity at 1M Power (AES) Nominal Impedance
12" 114Hz - 445Hz 105dB at 2.8V 300W
8" 445Hz - 7.55kHz 111dB at 4V 200W 16Ω
2 x 1" 5.77kHz - 18kHz 113dB at 4V 100W 16Ω
