RES 1

Funktion-One

Radical and Accurate Two-Way Loudspeaker

Res 1 is a radical, 2-way loudspeaker enclosure, resulting from Tony Andrews’ 40 years pioneering research and development of high efficiency cone midrange.

Its unique Funktion-One 5” wide-range driver eliminates the need for a compression driver with the associated harshness and distortion. In conjunction with the dedicated Axhead loaded waveguide, the Res 1 smoothly reproduces both midrange and high frequencies with exceptional coherency and detail. The accuracy, projection and imaging detail of the Res 1 make it ideally suited to high intelligibility applications including theatrical use. It has a rear recess that can be fitted with the optional PX1 passive crossover module and the waveguide can be rotated for use in either vertical or horizontal formats.

Key Features

  • Innovative cone driver technology
  • Very low distortion
  • Funktion-One designed Neodymium drivers
  • Rotatable mid-high waveguide for horizontal use
  • Integral 35mm pole mount
  • Optional full grill for discreet appearance
  • Optional Passive Crossover Module (PX1)
  • Complete range of flying and mounting options
  • R1
  • Res 1 by 4
  • R1
  • Res 1 by 4
Res1 MTV Cannes 06

Technical Specification

Usable Bandwidth (-3DB)
65Hz - 15kHz
Weight
19kg (42lbs)
Nominal Dispersion
40° Horizontal x 25° Vertical
Connectors
2 x Neutrik NL4
Drivers
Driver Operating Band Sensitivity at 1M Power (AES) Nominal Impedance
12" 25Hz - 520Hz 102dB at 2.8V 350W
5" 520Hz - 15kHz 112dB at 3.5V 75W 12Ω
12" + 5" (Optional PX1 Passive Module) 25Hz - Up 102dB at 2.8V 350W
