PSM318 DJ Monitor delivers outstanding full frequency output, accuracy and immediacy, setting a new benchmark for DJs looking for ultimate stage sound.
It comprises a new double 18” bass reflex enclosure - providing very strong near-field sub-bass - with a separate triple concentric enclosure for the rest of the frequency spectrum. These two enclosures join with a clever quick-latch system to provide simple angle adjustment for different stage positions and DJ heights. The triple concentric arrangement of the bass reflex enclosure combines a very high power 18” driver with a coaxially mounted two-way compression driver. The natural materials used in the midrange section of the compression driver give previously unheard clarity and definition to the vocal range and the ultra-fast 18" driver with its Neodymium magnet and 5” voice coil delivers excellent mid-bass definition. The overall design has been optimised to minimise sight line impact. These radical DJ monitors were first used at Space in Ibiza to widespread acclaim and have also recently been deployed in several ground-breaking clubs State-side as well as on the Ultra stage at the WMC in Miami and other leading Dance Events around the World.
| Driver | Operating Band | Sensitivity at 1M | Power (AES) | Nominal Impedance |
|---|---|---|---|---|
| 2 x 18" (PSM318L) | 25Hz - 85Hz | 101dB at 2V | 1100W | 4Ω |
| 18" | 85Hz - 694Hz | 104dB at 2.8V | 600W | 8Ω |
| 5" + VHF (V1) | 694Hz - Up | 112dB at 2.8V | 80W | 8Ω |
| MF + HF (V2) | 600Hz - Up | 111dB at 2.8V | 200W | 8Ω |
